关于 TOUGHRADIUS

             )                        )   (                (       (              (
  *   )   ( /(            (        ( /(   )\ )     (       )\ )    )\ )           )\ )              (
` )  /(   )\())      (    )\ )     )\()) (()/(     )\     (()/(   (()/(      (   (()/(     (   (    )\ )
 ( )(_)) ((_)\       )\  (()/(    ((_)\   /(_)) ((((_)(    /(_))   /(_))     )\   /(_))    )\  )\  (()/(
(_(_())    ((_)   _ ((_)  /(_))_   _((_) (_))    )\ _ )\  (_))_   (_))    _ ((_) (_))     ((_)((_)  /(_))
|_   _|   / _ \  | | | | (_)) __| | || | | _ \   (_)_\(_)  |   \  |_ _|  | | | | / __|    \ \ / /  (_) /
  | |    | (_) | | |_| |   | (_ | | __ | |   /    / _ \    | |) |  | |   | |_| | \__ \     \ V /    / _ \
  |_|     \___/   \___/     \___| |_||_| |_|_\   /_/ \_\   |___/  |___|   \___/  |___/      \_/     \___/

                                          /)
    _   __   __   _    _/_  ___       _  (/   _  _/_  __      _ _/_      _  ______
    (_(/ (_(/ (_(/  .  (__ (_) (_(_  (_/_/ )_/_)_(__ / (_(_(_(__(__  .  (__(_) // (_
                                    .-/
                                   (_/

TOUGHRADIUS 是一个开源的Radius服务软件,支持标准RADIUS协议(RFC 2865, RFC 2866),提供完整的AAA实现。支持灵活的策略管理,支持各种主流接入设备并轻松扩展,具备丰富的计费策略支持。

至 6.x 版本开始,基于Java语言重新开发。提供了一个高性能的 RADIUS 处理引擎,同时提供了一个简洁易用的 WEB管理界面,可以轻松上手。

TOUGHRADIUS 的功能类似于 freeRADIUS,但它使用起来更简单,更易于扩展开发。

链接

快速开始

系统环境依赖

数据库初始化

数据库的安装配置请自行完成,首先确保你的数据库服务器已经运行

运行创建数据库脚本以及创建专用用户

create database toughradius DEFAULT CHARACTER SET utf8mb4 COLLATE utf8mb4_unicode_ci;
GRANT ALL ON toughradius.* TO raduser@'127.0.0.1' IDENTIFIED BY 'radpwd' WITH GRANT OPTION;FLUSH PRIVILEGES;

创建数据库表

create table if not exists tr_bras
(
    id bigint auto_increment primary key,
    identifier varchar(128) null,
    name varchar(64) not null,
    ipaddr varchar(32) null,
    vendor_id varchar(32) not null,
    portal_vendor varchar(32) not null,
    secret varchar(64) not null,
    coa_port int not null,
    ac_port int not null,
    auth_limit int null,
    acct_limit int null,
    status enum('enabled', 'disabled') null,
    remark varchar(512) null,
    create_time datetime not null
);

create index ix_tr_bras_identifier on tr_bras (identifier);

create index ix_tr_bras_ipaddr on tr_bras (ipaddr);

create table if not exists tr_config
(
    id bigint auto_increment primary key,
    type varchar(32) not null,
    name varchar(128) not null,
    value varchar(255) null,
    remark varchar(255) null
);

create table if not exists tr_subscribe
(
    id bigint auto_increment primary key,
    node_id bigint default 0 not null,
    subscriber varchar(32) null,
    realname varchar(32) null,
    password varchar(128) not null,
    domain varchar(128) null,
    addr_pool varchar(128) null,
    policy varchar(512) null,
    is_online int null,
    active_num int null,
    bind_mac tinyint(1) null,
    bind_vlan tinyint(1) null,
    ip_addr varchar(32) null,
    mac_addr varchar(32) null,
    in_vlan int null,
    out_vlan int null,
    up_rate bigint null,
    down_rate bigint null,
    up_peak_rate bigint null,
    down_peak_rate bigint null,
    up_rate_code varchar(32) null,
    down_rate_code varchar(32) null,
    status enum('enabled', 'disabled') null,
    remark varchar(512) null,
    begin_time datetime not null,
    expire_time datetime not null,
    create_time datetime not null,
    update_time datetime null
);

create index ix_tr_subscribe_create_time
    on tr_subscribe (create_time);

create index ix_tr_subscribe_expire_time
    on tr_subscribe (expire_time);

create index ix_tr_subscribe_status
    on tr_subscribe (status);

create index ix_tr_subscribe_subscriber
    on tr_subscribe (subscriber);

create index ix_tr_subscribe_update_time
    on tr_subscribe (update_time);

插入测试数据

INSERT INTO toughradius.tr_bras
(identifier, name, ipaddr, vendor_id, portal_vendor,secret, coa_port,ac_port, auth_limit, acct_limit, STATUS, remark, create_time)
VALUES ('radius-tester', 'radius-tester', '127.0.0.1', '14988',"cmccv1", 'secret', 3799,2000, 1000, 1000, NULL, '0', '2019-03-01 14:07:46');

INSERT INTO toughradius.tr_subscribe
(node_id,  subscriber, realname, password, domain, addr_pool, policy, is_online, active_num,
 bind_mac, bind_vlan, ip_addr, mac_addr, in_vlan, out_vlan, up_rate, down_rate, up_peak_rate,
 down_peak_rate, up_rate_code,down_rate_code, status, remark, begin_time, expire_time, create_time, update_time)
VALUES (0, 'test01', '', '888888',  null, null, null, null, 10, 0, 0, '', '', 0, 0, 10.000, 10.000, 100.000, 100.000,
        '10', '10', 'enabled', '', '2019-03-01 14:13:02', '2019-03-01 14:13:00', '2019-03-01 14:12:59', '2019-03-01 14:12:56');

运行主程序

java -jar -Xms256M -Xmx1024M /opt/toughradius-latest.jar  --spring.profiles.active=prod

注意 jar 文件(toughradius-latest.jar)的路径

Linux systemd 服务配置

/opt/application-prod.properties

# web访问端口
server.port = 1816

# 如果启用 https, 取消以下注释即可
#server.security.require-ssl=true
#server.ssl.key-store-type=PKCS12
#server.ssl.key-store=classpath:toughradius.p12
#server.ssl.key-store-password=toughstruct
#server.ssl.key-alias=toughradius

# 日志配置,可选 logback-prod.xml 或 logback-dev.xml, 日志目录为 /var/toughradius/logs
logging.config=classpath:logback-prod.xml

# 数据库配置
spring.datasource.url=${RADIUS_DBURL:jdbc:mysql://127.0.0.1:3306/toughradius?serverTimezone=Asia/Shanghai&useUnicode=true&characterEncoding=utf-8&allowMultiQueries=true}
spring.datasource.username=${RADIUS_DBUSER:raduser}
spring.datasource.password=${RADIUS_DBPWD:radpwd}
spring.datasource.max-active=${RADIUS_DBPOOL:120}
spring.datasource.driver-class-name=com.mysql.cj.jdbc.Driver

/usr/lib/systemd/system/toughradius.service

[Unit]
Description=toughradius
After=syslog.target

[Service]
WorkingDirectory=/opt
User=root
LimitNOFILE=65535
LimitNPROC=65535
Type=simple
ExecStart=/usr/bin/java -server -jar -Xms256M -Xmx1024M /opt/toughradius-latest.jar  --spring.profiles.active=prod
SuccessExitStatus=143

[Install]
WantedBy=multi-user.target

如果了解 spring systemd和配置原理,可以根据自己的实际需要进行修改

通过以下指令启动服务

systemctl enable toughradius
systemctl start toughradius
